We Supply Whole Line Solution of Thermoforming and Packaging. Our New Type of Four Station Thermoforming Machine is Much more advanced Products in China
10 Years
| Ask Lasest Price | |
| Brand Name : | Jinghua |
| Certification : | CE SGS |
| Model Number : | JH60J |
| Price : | 20000-28000USD |
| Delivery Time : | 20 Days after got your deposit and tube samples |
| Payment Terms : | 30% TT as down payment,70% TT before dispatch the machine, or 100% LC at sight |
| Supply Ability : | 20 SETS PER MONTH |
Aluminume Tube Automatic Tube Filling and Sealing Machine For Pharmacy Products
Application: Pharmacy, Daily Chemicial ,Cosmetic and Related Products
This machine can seal Plastic Tube, Plastic/alu Lamitated tube ETC.
Specifications
JH-60Z | |||||
Configuration Standard | Technical Parameters | Remarks | |||
n Infrastructure | |||||
Main Machine Landing Area | (about) 2m2 | ||||
Working Area | (about)12㎡ | ||||
Water Chiller Landing Area | (about)1㎡ | ||||
Working Area | (about)2㎡ | ||||
Whole Machine (L×W×H) | 1950×1000×1800mm | ||||
Integrated Structure | Union mode | ||||
Weight | (about)850Kg | ||||
n Machine case body | |||||
Case Body Material | 304 | ||||
Opening Mode of Safety Guard | Handle Door | ||||
Safety Guard Material | Organic Glass | ||||
Frame Below Platform | Stainless Steel | ||||
Case Body Shape | Square-shape | ||||
Power, Main Motor etc. | |||||
Power Supply | 60Hz/380V 3P | ||||
Main Motor | 1.1KW | ||||
Hot Air Generator | 3KW | ||||
Water Chiller | 1.5KW | ||||
Jacket barrel heating power | 2 KW | optional | |||
Jacket barrel blending power | 0.18 KW | optional | |||
Machine Show Room For Aluminume Tube Automatic Tube Filling and Sealing Machine For Pharmacy Products
Samples Display For Aluminume Tube Automatic Tube Filling and Sealing Machine For Pharmacy Products
|
|
